Metal Roof Panel System C1300 / C1301

C1300/C1301 Metal Roof System

Designed to accommodate arched canopies and walkway covers, Englert’s curved version of the popular A1300/A1301 metal roof panel meets the needs of today’s architects. This curved metal roof panel, at 1 ½" tall, can be reduced to a minimum radius of 24" in aluminum or 100" in steel.

Both systems, although rugged in design, require a solid deck for installation. The C1300 carries the UL-90 listing with proper fastening. These metal roof panels can be locked with a 90° or 180° fold, widths are adjustable from 12" to 20”.

C1300/C1301 Roof Panel Details

Good for mansard or fascia
Architectural detail capability
Tight radius curving capacity
Shallow slope (less than 3”/12”)
Narrow seam

Mechanical seam
ASTM water & air tested
ASTM-E84 tested (Class A Fire rating)
ASTM-E1592 tested

UL 580, Class 90
Dade county tested
Florida building code compliant
Weather tightness warranties

Roofing Color Chart

Englert is one of the few single-source metal roof manufacturers with an in-house paint line. Whether the design calls for a natural weathered appearance or bright, high-performance, full-strength fluorocarbon colors, we’ve got a color for every project.
